Pax M4 – Japanese Rangefinder from the Late 1950s 📸🇯🇵 The Pax M4 was produced between 1958 and 1960 by Yamato Kōki Kōgyō. This compact 35mm rangefinder camera was marketed as an affordable alternative to expensive Leica and Canon models of the era. Depending on the export market, it was also sold under names like Pal, Rex, Atlas, and more. Many units were sold through PX stores to American soldiers stationed in Japan. ✨ Design & Build The Pax M4 is a solid, all-metal camera measuring about 75 × 110 × 65 mm and weighing ~0.55 kg. Styled like a mini-Leica, it has a silver top plate with black leatherette covering. Notably, it has no strap lugs – it was meant to be carried in its leather case with shoulder strap. Film loading is easy thanks to the removable back panel, and the advance system uses a simple metal clip. The modern-for-its-time rewind lever made film handling much quicker. 🔍 Lens & Shutter Equipped with a Luminor Anastigmat 45mm f/2.8, the Pax M4 delivers surprisingly sharp results, comparable to a Tessar-type design. The front element is coated, though flare and contrast loss can occur in backlight – a lens hood is highly recommended. The coupled rangefinder makes focusing straightforward, with a minimum distance of 1m. A small focus tab makes adjustment smooth. The leaf shutter is whisper-quiet, with speeds of 1/10–1/300 sec + Bulb, plus a mechanical self-timer. ⚙️ Features 35mm film, frame size 24×36mm Apertures f/2.8–f/16 F & X flash sync options (bulbs or electronic flash) Lever wind with auto frame counter Accessory shoe for finders & flashes 📦 Accessories The Pax M4 was offered as a mini-system camera, with: Wide & tele auxiliary lenses + matching finders Filters & lens hoods Leather case with strap 🎞️ In Use The Pax M4 surprises with its quiet shutter, sturdy feel, and crisp images. Black-and-white film shows great sharpness, while color film also looks good with modern stocks. Its biggest weakness is flare in strong light, plus the fact that many surviving examples suffer from stiff focusing or sticky shutters (usually fixable with a CLA). 📜 Place in History The Pax M4 was Yamato’s last true rangefinder before the company ceased camera production around 1961/62. Today, it stands as a charming, capable, and historic little rangefinder, one of the last traces of a lesser-known Japanese manufacturer. #PaxM4 #PaxCamera #YamatoKōki #JapaneseRangefinder #1950sCameras #VintageRangefinder #35mmPhotography #ClassicCamera #FilmPhotography #ShootFilmStayBroke #AnalogPhotography #FilmCommunity #RangefinderCamera #VintageLens #ClassicCameraGear #FilmIsNotDead #VintageRangefinder #MiniLeica #RangefinderLove

Photographer:

rvanstormbroek

Uploaded:

2025-09-07

Tags:

1950scameras 35mmphotography analogphotography classiccamera classiccameragear filmcommunity filmisnotdead filmphotography japaneserangefinder minileica paxcamera paxm4 rangefindercamera rangefinderlove shootfilmstaybroke vintagelens vintagerangefinder yamatokōki

Camera:

Pax M4

Film:

fom

Albums:

Pax M4
